Copper Expansion Joint
◎ Ua Haujlwm Siab---200 PSI Qhov siab tshaj plaws @ 70℉
◎ Axial Compression ---1/2" Yam tsawg kawg nkaus
◎ Axial Extension ---1/2" Yam tsawg kawg nkaus
Taw qhia
◎ Test Siab---300 PSI Yam tsawg kawg nkaus @ 70℉
◎ Ua Haujlwm Siab---200 PSI Qhov siab tshaj plaws @ 70℉
◎ Axial Compression ---1/2" Yam tsawg kawg nkaus
◎ Axial Extension ---1/2" Yam tsawg kawg nkaus
Khoom siv
|
Chav tsev |
Khoom siv |
|
Npog |
SIB 304 |
|
Copper End |
Tooj |
|
Daim ntaub |
SIB 304 |
|
Lwm tus |
SIB 304 |
|
Qauv nab npawb |
Cov yeeb nkab loj |
Zuag qhia tag nrho Length (IN) |
cev OD |
A (IN) |
B(IN) |
C(IN) |
OD |
|
PEB 075 |
3/4" |
11-1/2" |
0.875" |
2.2" |
1.5" |
6.75 |
2" |
|
ECCPS 100 |
1" |
11-1/2" |
1.125" |
2.2" |
1.5" |
6.75 |
2" |
|
PEB 125 |
1-1/4" |
12" |
1.375" |
2.2" |
1.75" |
6.75 |
2.75" |
|
PEB 150 |
1-1/2" |
12" |
1.625" |
2.2" |
1.75" |
6.75 |
2.75" |
|
ECCPS 200 |
2" |
12-1/4" |
2.215" |
2.2" |
1.75" |
6.75 |
3.5" |
|
ECCPS 250 |
2-1/2" |
13-1/4" |
2.625" |
2.2" |
2" |
6.85 |
4" |
|
ECCPS 300 |
3" |
13-1/4" |
3.125" |
2.2" |
2" |
6.85 |
4.5" |
|
ECCPS 400 |
4" |
14-1/2" |
4.13" |
2.2" |
2.5" |
7.5 |
6.3" |
Cim npe nrov: Tuam Tshoj tooj liab expansion sib koom ua ke manufacturers, lwm tus neeg, Hoobkas
